Page 2 of 2 TECHNICAL DATA Power suply Operating voltage 24 V~ ± 20 %, 50…60 Hz 24 V=-10%…+20 % 230 V~±15 %, 50…60 Hz Power consumption (at nominal voltage, with movement) AVM * K001 < 2.0 W < 3.0 VA AVM * K002 < 2.4 W < 4.0 VA Parameters Nominal force 1) Operating noise 2) (at nominal force) Response time Max. media temperature 3) 1000 N < 30 dB(A) Approx. 200 ms 0…100 °C Installation Dimensions W x H x D (mm) Weight (kg) AVM321: 60x187x88 AVM 322: 160x241x88 AVM321: 1.5 AVM322: 1.6 Standards and directives Degree of protection IP 54 (EN 60529) Protection class II EN60730 III EN60730 Standards and directives Additional information Fitting instructions 99.70.03 Declaration on materials and the environment MD 51.374 Declaration of incorporation P100012470 Manual & electrical connection diagram 99.70.05.01 Admissible ambient conditions Operating temperature -10…55 °C Storage and transport temperature -40…80 °C Humidity 5…85% rh No condensation 1) Actuating power 1000 N under nominal conditions (24 V or 230 V, 25 °C ambient temperature, 50 Hz). With boundary conditions (19.2 V~ / 28.8 V~ / 21.6 V= / 28.8 V=, -10 °C / 55 °C, 60 Hz) and positioning time, the actuating tensile force is minimised to 800 N 2) Operating noise with the slowest positioning time, test distance 1m 3) Use the appropriate accessory when the temperature of the medium is > 100 °C (temperature adaptor). POWER CONSUMPTION AT NOMINAL VOLTAGE CE CONFORMITY Type AVM * K001 AVM * K002 Positioning time (s/mm) 6 (12) 12 (6) 6 (12) 12 (6) Status Standstill *) Sizing Operation Standstill *) Sizing Operation Active power P (W) < 0,35 < 2,4 < 0,3 < 2,0 Apparent power S (VA) ≥ 5,0 < 4,0 ≥ 4,0 < 3,0 *) Standstill = actuator in the end position, voltage applied to terminal 1 or 2, motor switched off. ACCESSORIES EMC Directive 2004/108/EC EN 61000-6-1 15/9 H1F EN 61000-6-2 EN 61000-6-3 EN 61000-6-4 Low-voltage Directive 2006/95/EC EN 60730-1 EN 60730-2-14 Over-voltage category III Degree of contamination II Maximum altitude. 2000 m Machinery Directive 2006/42/EC in accordance with Annex II B EN 12100 Type Description 1-0152285 Temperature adaptor for media temperature > 100 °C … 240 °C 1-0147655 Cable glands M20×1.5 IP68 www.cloriuscontrols.com 3 237
