Page number 2
SECTION 4 – Curb Valves Ball Type Curb Valves Part Number E-1901 E-1949SG E-1921 E-1901 E-1949SG E-1921 Description Inlet: Copper flare nut Outlet: F.I.P. thread. Quarter turn check. 360° turn option available by noting L/S to order Jones® 110 Conductive Compression Connection (Super Grip) for soft/annealed copper and CTS PE* tubing - both ends. Quarter turn check. 360° turn option available by noting L/S to order Inlet: Pack Joint Connection for CTS O.D* tubing Outlet: F.I.P. thread. Quarter turn check. 360° turn option available by noting L/S to order Sizes 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" E-1900 E-1945 E-1921SG Part Number Description E-1900 F.I.P. thread - both ends. Quarter turn check 360° turn option available by noting L/S to order E-1945 E-1921SG Inlet: M.I.P. thread. Quarter turn check Outlet: F.I.P thread 360° turn option available by noting L/S to order Inlet: Jones® 110 Conductive Compression Connection (Super Grip) for soft/annealed copper and CTS PE* tubing Outlet: F.I.P. thread. Quarter turn check. 360° turn option available by noting L/S to order E-1949 Pack Joint Connection for CTS O.D* tubing - both ends. Quarter turn check. 360° turn option available by noting L/S to order E-1949 Sizes 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" E-1986 E-1902 E-6501SG Part Number Description E-1986 Inlet: Pack Joint Connection for IPS PVC* tubing Outlet: F.I.P. thread. Quarter turn check. 360° turn option available by noting L/S to order E-1902 Copper flare nut - both ends. Quarter turn check. 360° turn option available by noting L/S to order E-6501SG E-6502 Jones® 110 Conductive Compression Connection (Super Grip) for soft/annealed copper and CTS PE* tubing - both ends. 360° turn option available by noting L/S to order. Stop and drain F.I.P. thread - both ends. Quarter turn check. 360° turn option available by noting L/S to order. Stop and drain E-6502 Sizes 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" 3/4" 1" 1-1/2" 2" JONES Curb Valves are manufactured and tested in accordance with ANSI/AWWA C-800. Components in contact with potable water will also comply with latest requirements of the Federal Safe Drinking Water Act. *See charts on pages 5-6 for tubing and pipe that may be used with these connections. 2 Rev 10-18
Page number 3
SECTION 4 – Curb Valves Ball Type Curb Valves Part Number E-1950 E-1951 E-1950 E-1951 Description IPS PE Pack Joint both ends. Quarter turn check. 360° turn option available by noting L/S to order IPS PE Jones® 110 Conductive Compression Connection (Super Grip) both ends with stop and drain Sizes 3/4" 1" 1-1/2" 2" 3/4" 1" JONES Curb Valves are manufactured and tested in accordance with ANSI/AWWA C-800. Components in contact with potable water will also comply with latest requirements of the Federal Safe Drinking Water Act. *See charts on pages 5-6 for tubing and pipe that may be used with these connections. Rev 10-18 3
